Recently, BIM (Building Information Modeling) technology has gained significant popularity and relevance. It allows for the visualization of the entire design process in 3D format, enabling quick adjustments to the project while considering their impact on adjacent systems. Many parameters, such as cable line lengths, are generated automatically, which not only reduces the risk of errors but also allows for more accurate calculations of cable product volumes. This, in turn, contributes to lowering the overall project cost and improving its accuracy.

This approach also aids in creating a detailed work schedule and tracking the progress of tasks, as well as facilitating the easy approval of changes and controlling the accuracy of design documentation.

Considering new technologies, Patchwork has developed BIM templates for its range of modern solutions (see the list below). Our engineers are ready to provide templates for all popular components, ensuring convenience when designing cable infrastructure systems for data centers based on Patchwork solutions.

The following templates in Revit 2019 format have already been published on the website, on the relevant product pages.

List of Templates:

1.    Flex point - mounting frame 19" for cable trays
17000003    FP - Mounting Frame 19", 2U, black
17000004    FP - Mounting Frame 19", 3U, black
17000005    FP - Mounting Frame 19", 4U, black
17000008    FP - Mounting Frame 19", 6U, black

2.    Flex point - vertical cable manager
17000021    FP - Vertical cable manager with cover, 6U, black
17000022    FP - Vertical cable manager with cover, 4U, black

3.    Cercis - High Density Fiber Patch Panel
30100001    Cercis - High Density Fiber Patch Panel 1U with front cable management, sliding, black
30100003    Cercis - High Density Fiber Patch Panel 4U with front cable management, sliding, black

4.    Currant – Fiber preterminated cassette
30214001    CC4 - Preterminated Cassette 12 x 50/125 OM4, MTP(12)f/LC Duplex, type UW, ULL
30214002    CС4 - Preterminated Cassette 12 x 50/125 OM5, MTP(12)f/LC Duplex, type UW, ULL
30214003    CC4 - Preterminated Cassette 12 x 09/125 OS2, MTP(12)f/LC-UPC Duplex, тип UW, ULL
30216001    СС6 - Preterminated Cassette 8 x 50/125 OM4, MTP(8)f/LC Duplex, тип UW, ULL
30216002    СС6 - Preterminated Cassette 8 x 50/125 OM5, MTP(8)f/LC Duplex, тип UW, ULL
30216003    СС6 - Preterminated Cassette 8 x 09/125 OS2, MTP(8)f/LC-UPC Duplex, тип UW, ULL

5.    Currant – Fiber Adapter cassette
30224001    CA4 - Adapter cassette 6 x LC Duplex adapters (heather violet), MM
30224002    CA4 - Adapter cassette 6 x LC Duplex adapters (yellow green), MM
30224003    CA4 - Adapter cassette 6 x LC-UPC Duplex adapters (blue), SM
30226001    CA6 - Adapter cassette 4 x LC Duplex adapters (heather violet), MM
30226002    CA6 - Adapter cassette 4 x LC Duplex adapters (yellow green), MM
30226003    CA6 - Adapter cassette 4 x LC-UPC Duplex adapters (blue), SM

6.    Currant – Preterminated сassette with front access
30244001    CF4 - Preterminated сassette with front access 8 x 50/125 OM4, MTP(8)m/LC Duplex, тип UW, ULL
30244002    CF4 - Preterminated сassette with front access 8 x 50/125 OM5, MTP(8)m/LC Duplex, тип UW, ULL
30244003    CF4 - Preterminated сassette with front access 8 x 09/125 OS2, MTP(8)m/LC-UPC Duplex, тип UW, ULL
